| Place of Origin: | CHINA |
| Brand Name: | JST |
| Certification: | ROHS |
| Model Number: | GHR-XV-S |
| Minimum Order Quantity: | - |
|---|---|
| Price: | Negotiable |
| Delivery Time: | 2-3week |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | Negotiable |
| Series: | GH | Pin: | 2-15 |
|---|---|---|---|
| Pitch: | 0.049" (1.25mm) | Rated Voltage: | 50V |
| Rated Current: | 1A | Temperature: | -25℃ To +85℃ |
| ConnectorType: | Receptacle | ApplicableWire: | 30-26AWG |
Features
Application
Connector Details
| TYPE | DESCRIPTION |
| Category | Connectors, Interconnects Rectangular Connectors - Housings |
| Mfr | JST Sales America Inc. |
| Series | GH |
| Package | Bulk |
| Part Status | Active |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 2-15 |
| Pitch | 0.049" (1.25mm) |
| Number of Rows | 1 |
| Row spacing | - |
| Mounting Type | Free Hanging (In-Line) |
| Contact Termination | Crimp |
| Fastening Type | Latch Lock |
| Color | Natural |
| Features | - |
| Note | Contacts Not Included |
Product Specification
| No. of circuits | Model No. | Dimensions(mm) | |
| A | B | ||
| 2 | GHR-02V-S | 1.25 | 3.75 |
| 3 | GHR-03V-S | 2.50 | 5.00 |
| 4 | GHR-04V-S | 3.75 | 6.25 |
| 5 | GHR-05V-S | 5.00 | 7.50 |
| 6 | GHR-06V-S | 6.25 | 8.75 |
|
7 |
GHR-07V-S | 7.50 | 10.00 |
| 8 | GHR-08V-S | 8.75 | 11.25 |
| 9 | GHR-09V-S | 10.00 | 12.50 |
| 10 | GHR-10V-S | 11.25 | 13.75 |
| 11 | GHR-11V-S | 12.50 | 15.00 |
| 12 | GHR-12V-S | 13.75 | 16.25 |
| 13 | GHR-13V-S | 15.00 | 17.50 |
| 14 | GHR-14V-S | 16.25 | 18.75 |
| 15 | GHR-15V-S | 17.50 | 20.00 |
Wire &Cable Information
| German standard | ||
| FLRY-B | 0.35/0.5/0.75/1.5/2.5/4.0 | |
| Japanese standard | ||
| TXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
| GXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
| UL | ||
| UL1007 | UL1061 | UL1015 |
| UL1569 | UL3239 | UL1430 |
| UL | ||
| UL2464 | UL20276 | UL2586 |
| UL2733 | ||
| Jacket material | ||
| PVC | PE | TPU |
| PU | TPE | XLPE |
| PUR | PTFE | Silicon rubber |
| External protective materials | ||
| PA flexible bellows | ||
| PP bellows | ||
| TPE Nylon Braided reticulated tube | ||
| Electrical tape | ||
| High temperature resistant flannel tape | ||
| PVC sleeve | ||
| Heat shrinkable tube | ||
| FAQ | |
| MOQ | 5-100000PCS |
| LEAD TIME | Production 2-3week |
| Transportation | FEDEX.UPS.DHL.SF.transportation line |
| Payment method | T/T,PAYPAL,ALIPAY,ALIBABA |
| Production standard | IPC/WHMA-A-620 |
| Product certification | ROHS2.0/3.0,UL |
| Factory related certification | ISO9001/ITFA16949/ISO13485 |
