Place of Origin: | CHINA |
Brand Name: | MOLEX |
Certification: | ROHS |
Model Number: | 09-50-1XX1 |
Minimum Order Quantity: | - |
---|---|
Price: | Negotiable |
Delivery Time: | 2-3week |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | Negotiable |
Series: | SPOX 5195 | Pin: | 2-12 |
---|---|---|---|
Pitch: | 0.156" (3.96mm) | ConnectorType: | Receptacle |
Rated Current: | 5A | Rated Voltage: | 250V |
Color: | Natural | Temperature: | -40° To +105°C |
Features
Multiple contact points and terminal protection
2. Friction locks
Secure mating retention
3. Polarization keys
Ensure correct mating
4. Voids, various platings, and kinked tail options
Meets various design needs
5. W-to-B, W-to-W, B-to-B
Versatile configurations
6. Headers are molded in LCP high-temperature plastic
Meet Lead-free processing requirements
7. Panel mounting feature permits up to 3 mm (0.120") misalignment in horizontal and vertical directions
Permits blind-mating of products as connectors can self-align
8. First-mate/last-break circuits
Provide sequential engagement of contacts for design flexibility
9. Robust alignment features
Virtually eliminate contact damage
Application
Signal, wire to board
Connector Details
TYPE | DESCRIPTION |
Category | Connectors, Interconnects Rectangular Connectors - Housings |
Mfr | Molex |
Series | SPOX 5195 |
Package | Bulk |
Part Status | Active |
Connector Type | Receptacle |
Contact Type | Female Socket |
Number of Positions | 2-12 |
Pitch | 0.156" (3.96mm) |
Number of Rows | 1 |
Row spacing | - |
Mounting Type | Free Hanging (In-line) |
Contact Termination | Crimp |
Fastening Type | Locking Ramp |
Color | Natural |
Features | - |
Note | Contacts Not Included |
Product Specification
Multi-core,SPOX 5195 Series 3.96mm Single-Row Connectors with Friction Ramp |
|
Number of position | Assembly Item Number |
2 | 09-50-1021 |
3 | 09-50-1031 |
4 | 09-50-1041 |
5 | 09-50-1051 |
6 | 09-50-1061 |
7 | 09-50-1071 |
8 | 09-50-1081 |
9 | 09-50-1091 |
10 | 09-50-1101 |
11 | 09-50-1111 |
12 | 09-50-1121 |
Wire &cable Information
German standard | ||
FLRY-B | 0.35/0.5/0.75/1.5/2.5/4.0 | |
Japanese standard | ||
TXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
GXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
UL | ||
UL1007 | UL1061 | UL1015 |
UL1569 | UL3239 | UL1430 |
UL | ||
UL2464 | UL20276 | UL2586 |
UL2733 | ||
Jacket material | ||
PVC | PE | TPU |
PU | TPE | XLPE |
PUR | PTFE | Silicon rubber |
External protective materials | ||
PA flexible bellows | ||
PP bellows | ||
TPE Nylon Braided reticulated tube | ||
Electrical tape | ||
High temperature resistant flannel tape | ||
PVC sleeve | ||
Heat shrinkable tube |
FAQ | |
MOQ | 5-100000PCS |
LEAD TIME | Production 2-3week |
Transportation | FEDEX.UPS.DHL.SF.transportation line |
Payment method | T/T,PAYPAL,ALIPAY,ALIBABA |
Production standard | IPC/WHMA-A-620 |
Product certification | ROHS2.0/3.0,UL |
Factory related certification | ISO9001/ITFA16949/ISO13485 |
