3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness

3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness

    • 3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness
    • 3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness
    • 3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness
    • 3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness
    • 3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness
  • 3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness

    Product Details:

    Place of Origin: China
    Brand Name: Molex
    Certification: UL/CE / ISO / TS16949 / IPC-620D
    Model Number: 43025 - 1400

    Payment & Shipping Terms:

    Minimum Order Quantity: 100set
    Price: Negotiable
    Packaging Details: Carton or Wood Box
    Delivery Time: 3-15D
    Payment Terms: T/T,PAYPAL,ALIPAY
    Supply Ability: 5000SET/D
    Contact Now
    Detailed Product Description
    Material: PA6 Color: Bk
    Pich: 3.0mm Cable: VDE Lify
    Highlight:

    car wiring harness

    ,

    auto electrical wiring harness

    3.0MM PICH black molex 43025 - 1400 connectors for Automobile Wire Harness



    Application : internal wiring of machines



    Advantage : Small spacing , Connector 2-24PIN ,Termial use 43030 series current up to 4A the chain wire harness , moving back and forth



    cable jacket can choose : PVC , PUR,TPE



    Temperature resistance : -40C°-105C°



    Voltage : 30V-600V



    Connector housing



    1 43025 - 0200 Double row 3 . 0MM , 2 * 1 2PIN connector
    2 43025 - 0400 Double row 3 . 0MM , 2 * 2 4PIN connector
    3 43025 - 0600 Double row 3 . 0MM , 2 * 3 6PIN connector
    4 43025 - 0800 Double row 3 . 0MM , 2 * 4 8PIN connector
    5 43025 - 1000 Double row 3 . 0MM , 2 * 5 10PIN connector
    6 43025 - 1200 Double row 3 . 0MM , 2 * 6 12PIN connector
    7 43025 - 1400 Double row 3 . 0MM , 2 * 7 14PIN connector
    8 43025 - 1600 Double row 3 . 0MM , 2 * 8 16PIN connector
    9 43025 - 1800 Double row 3 . 0MM , 2 * 9 18PIN connector
    10 43025 - 2000 Double row 3 . 0MM , 2 * 10 20PIN connector
    11 43025 - 2200 Double row 3 . 0MM , 2 * 11 22PIN connector
    12 43025 - 2400 Double row 3 . 0MM , 2 * 12 24PIN connector



    Termial



    1 43030 - 0001 20 - 24AWG , CHAIN TIN
    2 43030 - 0002 20 - 24AWG , CHAIN GOLD
    3 43030 - 0003 20 - 24AWG , CHAIN GOLD
    4 43030 - 0004 26 - 30AWG , CHAIN TIN
    5 43030 - 0005 26 - 30AWG , CHAIN GOLD
    6 43030 - 0006 26 - 30AWG , CHAIN GOLD
    7 43030 - 0007 20 - 24AWG , LOOSE TIN
    8 43030 - 0008 20 - 24AWG , LOOSE GOLD
    9 43030 - 0009 20 - 24AWG , LOOSE GOLD
    10 43030 - 0010 26 - 30AWG , LOOSE TIN
    11 43030 - 0011 26 - 30AWG , LOOSE GOLD
    12 43030 - 0012 26 - 30AWG , LOOSE GOLD
    13 43030 - 0038 UL1061 - 18AWG , CHAIN TIN




    Product Attributes Select All
    Categories Connectors , Interconnects
    Rectangular Connectors - Housings
    Manufacturer Molex , LLC
    Series Micro - Fit 3 . 0™ 43025
    Packaging Bulk
    Part Status Active
    Connector Type Receptacle
    Contact Type 24
    Pitch 0 . 118" (3 . 00mm )
    Number of Rows 2
    Row Spacing 0 . 118" (3 . 00mm )
    Mounting Type Free Hanging (In - Line )
    Contact Termination Crimp
    Fastening Type Latch Lock
    Color Black



    UL standard internal wiring
    UL1007 Hook-up Wire
    UL1015 Hook-up Wire
    UL1061 Hook-up Wire
    UL1185 Single Conductor Shielded Cable
    UL1316 Reinforced Hook-up Wire
    UL1330 FEP Insulated Wire
    UL1430 Crosslinked PVC Insulated Wire
    UL1452 Reinforced Hook-up Wire
    UL1533 Single Conductor Shielded Cable
    UL1569 Hook-up Wire
    UL1571 Hook-up Wire
    UL1672 Reinforced Hook-up Wire
    UL10064 FEP Insulated Wire
    UL10086 High Temperature Resistant Hook-up Wire
    UL10097 Crosslinked PVC Insulated Wire
    UL10272 Hook-up Wire
    UL10308 High Temperature Resistant Hook-up Wire
    UL2464 Multi-Conductor Shielded Cable
    UL2468 Flat Ribbon Wire
    UL2509 Multi-Conductor Cable
    UL2517 Multi-Conductor Shielded Cable
    UL2547 Multi-Conductor Shielded Cable
    UL2552 Multi-Conductor Shielded Cable
    UL2576 Multi-Conductor Cable
    UL2586 Multi-Conductor Cable
    UL2651 Flat Ribbon Wire
    UL2725 Multi-Conductor Shielded Cable
    UL2835 Multi-Conductor Shielded Cable
    UL2854 Multi-Conductor Shielded Cable
    UL2919 Low Voltage Multi-Conductor Shielded Cable
    UL20276 Multi-Conductor Shielded Cable
    UL20379 Multi-Conductor Shielded Cable
    UL21149 Multi-Conductor Shielded Cable
    UL21520 Multi-Conductor Cable
    UL3443 Hook-up Wire

    UL halogen-free wire
    UL11027 Hook-up Wire
    UL10983 Single Conductor Shielded Cable
    UL10982 Hook-up Wire
    UL10981 Hook-up Wire
    UL10984 Reinforced Hook-up Wire
    UL10986 Single Conductor Shielded Cable
    UL10987 Hook-up Wire
    UL11025 Hook-up Wire
    UL11028 Hook-up Wire
    UL11029 Hook-up Wire
    UL11045 Reinforced Hook-up Wire
    UL11047 Reinforced Hook-up Wire
    UL21451 Double Shielded Cable
    UL21452 Double Shielded Cable
    UL21455 Multi-Conductor Shielded Cable
    UL21456 Multi-Conductor Shielded Cable
    UL21457 Multi-Conductor Shielded Cable
    UL21458 Flat Ribbon Wire
    UL21461 Multi-Conductor Shielded Cable
    UL21474 Multi-Conductor Shielded Cable
    UL21476 Multi-Conductor Shielded Cable
    UL21515 Flat Ribbon Wire
    UL21517 Multi-Conductor Shielded Flat Ribbon Wiree

    Industrial electric wire

    Flexible Single Core Cable
    Flexible Multi-core Torsion Cable
    Flexible Multi-core Shielded/Non-Shielded Control Cable

    VDE standard wire

    LifY Single Core,extra fine wires with highest flexibility
    LIYY-Command Cable (Style 2464/300 V, (80°C)
    LIYY-TP-Command Cable-Twisted (Style 2464/300 V, (80°C)
    LIYCY-Shielding Command Cable (Style 2464/300 V, (80°C)
    LIYCY-TP-Shielding Command Cable-Twisted (Style 2464/300 V, (80°C)

    Automotive wire

    FLRY-A Automotive Wire Series
    FLRY-B Automotive Wire Series
    FLRYW Automotive Wire Series

    TWP Automotive Wire Series
    TXL Automotive Wire Series
    GXL Automotive Wire Series
    AVS Automotive Wire Series
    AVSS Automotive Wire Series

    Packaging & Shipping

    Export cartons
    (406mm*306mm*250mm)
