| Place of Origin: | CHINA |
| Brand Name: | JST |
| Certification: | ROHS |
| Model Number: | XHP-X |
| Minimum Order Quantity: | - |
|---|---|
| Price: | Negotiable |
| Delivery Time: | 2-3week |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | Negotiable |
| Series: | XH | Pin: | 1-16，20 |
|---|---|---|---|
| Pitch: | 0.098" (2.50mm) | ConnectorType: | Receptacle |
| Rated Voltage: | 250V | Rated Current: | 3A |
| Temperature: | -25℃ To +85℃ | ApplicableWire: | 30-22AWG |
Application
Connector Details
| TYPE | DESCRIPTION |
| Category | Connectors, Interconnects Rectangular Connectors - Housings |
| Mfr | JST Sales America Inc. |
| Series | XH |
| Package | Bulk |
| Part Status | Active |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 1-16,20 |
| Pitch | 0.098" (2.50mm) |
| Number of Rows | 1 |
| Row spacing | - |
| Mounting Type | Free Hanging (In-Line) |
| Contact Termination | Crimp |
| Fastening Type | - |
| Color | Natural |
| Features | - |
| Note | Contacts Not Included |
Product Specification
| No. of circuits | Model No. | Dimensions(mm) | ||
| A | B | C | ||
| 1 | XHP-1 | - | 3.2 | 4.8 |
| 2 | XHP-2 | 2.5 | 5.7 | 7.3 |
| 2 | Note1)XHP-2(10.0)-U | 10 | 13.2 | 14.8 |
| 3 | XHP-3 | 5 | 8.2 | 9.8 |
| 4 | XHP-4 | 7.5 | 10.7 | 12.3 |
| 5 | XHP-5 | 10 | 13.2 | 14.8 |
| 6 | XHP-6 | 12.5 | 15.7 | 17.3 |
| 6 | Note2)XHP-6(5.0)-U | 25 | 28.2 | 29.8 |
| 7 | XHP-7 | 15 | 18.2 | 19.8 |
| 8 | XHP-8 | 17.5 | 20.7 | 22.3 |
| 9 | XHP-9 | 20 | 23.2 | 24.8 |
| 10 | XHP-10 | 22.5 | 25.7 | 27.3 |
| 11 | XHP-11 | 25 | 28.2 | 29.8 |
| 12 | XHP-12 | 27.5 | 30.7 | 32.3 |
| 13 | XHP-13 | 30 | 33.2 | 34.8 |
| 14 | XHP-14 | 32.5 | 35.7 | 37.3 |
| 15 | XHP-15 | 35 | 38.2 | 39.8 |
| 16 | XHP-16 | 37.5 | 40.7 | 42.3 |
| 20 | XHP-20 | 47.5 | 50.7 | 52.3 |
Wire &cable Information
| German standard | ||
| FLRY-B | 0.35/0.5/0.75/1.5/2.5/4.0 | |
| Japanese standard | ||
| TXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
| GXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
| UL | ||
| UL1007 | UL1061 | UL1015 |
| UL1569 | UL3239 | UL1430 |
| UL | ||
| UL2464 | UL20276 | UL2586 |
| UL2733 | ||
| Jacket material | ||
| PVC | PE | TPU |
| PU | TPE | XLPE |
| PUR | PTFE | Silicon rubber |
| External protective materials | ||
| PA flexible bellows | ||
| PP bellows | ||
| TPE Nylon Braided reticulated tube | ||
| Electrical tape | ||
| High temperature resistant flannel tape | ||
| PVC sleeve | ||
| Heat shrinkable tube | ||
| FAQ | |
| MOQ | 5-100000PCS |
| LEAD TIME | Production 2-3week |
| Transportation | FEDEX.UPS.DHL.SF.transportation line |
| Payment method | T/T,PAYPAL,ALIPAY,ALIBABA |
| Production standard | IPC/WHMA-A-620 |
| Product certification | ROHS2.0/3.0,UL |
| Factory related certification | ISO9001/ITFA16949/ISO13485 |
Contact Us
| Mail: chenzhixiong @ linksunet.com | Phone : + 86-13641965642 |
| Tel : 021-58320567 / 58322073 | WeChat : 13641965642 |
