Place of Origin: | CHINA |
Brand Name: | JST |
Certification: | ROHS |
Model Number: | NSHR-02V-S |
Minimum Order Quantity: | - |
---|---|
Price: | Negotiable |
Delivery Time: | 2-3week |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | Negotiable |
Series: | NSH | Pin: | 2 |
---|---|---|---|
Pitch: | 1.0mm | Rated Voltage: | 50V |
Rated Current: | 1A | Temperature: | -25℃ To +85℃ |
ConnectorType: | Receptacle | ApplicableWire: | 32-28AWG |
Features
Connector Details
TYPE | DESCRIPTION |
Category | Connectors, Interconnects Rectangular Connectors - Housings |
Mfr | JST Sales America Inc. |
Series | NSH |
Package | Bulk |
Part Status | Active |
Connector Type | Receptacle |
Contact Type | Female Socket |
Number of Positions | 2 |
Pitch | 0.039" (1.00mm) |
Number of Rows | 1 |
Row spacing | - |
Mounting Type | Free Hanging (In-Line) |
Contact Termination | Crimp |
Fastening Type | Latch Lock |
Color | Natural |
Features | - |
Note | Contacts Not Included |
Product Specification
No. of circuits | Model No. | Dimensions(mm) | |
A | B | ||
2 | NSHR-02V-S | *2.0 | *5.0 |
3 | NSHR-03V-S | 2.0 | 5.0 |
4 | NSHR-04V-S | 3.0 | 6.0 |
5 | NSHR-05V-S | 4.0 | 7.0 |
6 | NSHR-06V-S | 5.0 | 8.0 |
7 | NSHR-07V-S | 6.0 | 9.0 |
8 | NSHR-08V-S | 7.0 | 10.0 |
9 | NSHR-09V-S | 8.0 | 11.0 |
10 | NSHR-10V-S | 9.0 | 12.0 |
11 | NSHR-11V-S | 10.0 | 13.0 |
12 | NSHR-12V-S | 11.0 | 14.0 |
13 | NSHR-13V-S | 12.0 | 15.0 |
14 | NSHR-14V-S | 13.0 | 16.0 |
15 | NSHR-15V-S | 14.0 | 17.0 |
Wire &cable Information
German standard | ||
FLRY-B | 0.35/0.5/0.75/1.5/2.5/4.0 | |
Japanese standard | ||
TXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
GXL | 22AWG/20AWG/18AWG/16AWG/14AWG | |
UL | ||
UL1007 | UL1061 | UL1015 |
UL1569 | UL3239 | UL1430 |
UL | ||
UL2464 | UL20276 | UL2586 |
UL2733 | ||
Jacket material | ||
PVC | PE | TPU |
PU | TPE | XLPE |
PUR | PTFE | Silicon rubber |
External protective materials | ||
PA flexible bellows | ||
PP bellows | ||
TPE Nylon Braided reticulated tube | ||
Electrical tape | ||
High temperature resistant flannel tape | ||
PVC sleeve | ||
Heat shrinkable tube |
FAQ | |
MOQ | 5-100000PCS |
LEAD TIME | Production 2-3week |
Transportation | FEDEX.UPS.DHL.SF.transportation line |
Payment method | T/T,PAYPAL,ALIPAY,ALIBABA |
Production standard | IPC/WHMA-A-620 |
Product certification | ROHS2.0/3.0,UL |
Factory related certification | ISO9001/ITFA16949/ISO13485 |
